VGA Module (15pin)

VGA Module (15pin)
Number: LKPF013
  • Product introduction

Name: VGA Module 15pin

Model LKPF013

Product Features: support one group VGA image transmission

Size: 48*24mm



Product Instructions

Using cable: VGA cable 3+6

Wiring method:

1 to red wire,

6 to shield layer of red wire,

2 to green wire.

7 to green wire shield layer,

3 to blue wire,

8 to blue wire shield layer,

Outside shield layer to GND

13 to yellow wire,

14 to white wire,

10 to black wire,

11 to brown wire,

If wire colors are different, only request agreement of the 2 sides wire colors
